Scuba –Close Coupled Submersible Pumps

APPLICATIONS

Water supply from rain water tanks or reservoirs, 6″ wells, basins and watercourses.
Sprinkler systems.
Pressure boosting with pump inserted directly in tank or well, to avoid suction problems and noise.
Water display, fountains.

SPECIFICATIONS

Delivery: up to 7,5 m3/h
Head: up to 75,5 m
Maximum pump overall diameter: 128 mm
Maximum immersion depth: 20 m
Maximum permissible quantity of suspended sand: 25 g/m3
Passage of solids up to 2.5 mm
Delivery port: Rp 1′/4″
Rated motor power: 0.55 to 1.1 kW
Single· phase motor: 220-240 V, 50 Hz, built-in automatic reset overload protection. A control box with 2-pole switch and capacitor is available on request
Three-phase motor: 380-41 5 V, 50 Hz; overload protection to be provided by user and installed in the control box (see control box section)
Maximum supply voltage variations: ± 5%
Class F insulation
Can also operate in horizontal position
Maximum number of starts per hour, at regular intervals:
25 for motors up to 0.9 kW.
20 for motors 1.1 kW and up
Maximum temperature of water in contact with the motor: 40°C (continuous use)

CONSTRUCTION FEATURES

Dry Motor

Sealing System

The silicon carbide mechanical seal, highly resistant to abrasion and wear, and the lip seal, continuously lubricated thanks to the special design of the oil chamber, ensure the absolute tightness of the motor seal.
In the event of dry running, the sealing system will not be damaged and the motor will not suffer from infiltration.
The oil used complies with FDA (FOOD AND DRUG ADMINISTRATION) standards.

Single-phase models with float (CG) are also available
